Figure 5-218 Register
Step 2 Click to enable the function.
Step 3 Congure the parameters.
Table 5-67 Register parameters
Function
Description
Server Address
Enter the IP address or domain name of the server that you want to
register to.
Port Enter the port of the server.
Sub-Device ID Enter the ID allocated by the server.
Step 4 Click Apply.
5.11.17 Switch
Background Information
After setting Switch, when an IPC is connected to the PoE port, the system automatically assigns
the IP address to the IPC according to the dened IP segment, and the NVR will automatically
connect to the IPC.
●
Only models with PoE ports support this function.
●
Do not connect the PoE port with a switch, otherwise it will cause connection failure.
●
This function is enabled by default, and the IP segment start from 10.1.1.1. We recommend you
use the default setting.
User's Manual
337
