Figure 5-217 Alarm center
Step 2 Click to enable the function.
Step 3 Congure the parameters.
Table 5-66 Alarm center parameters
Parameter
Description
Protocol Type Select a protocol type.
Server Address
The IP address and communication port of the PC installed with alarm
client.
Port
Auto Report Plan Select time cycle and specic time for uploading alarm.
Step 4 Click Apply.
5.11.16 Register
You can register the Device into the specied proxy server which acts as the transit to enable the
client software to access the Device
Prerequisites
●
The proxy server has been deployed.
●
The Device, the proxy server and the device running the client software are on the same
network.
Procedure
Step 1 Select Main Menu > NETWORK > Register.
User's Manual
336
