2. Congure parameters.
Table 5-48 Main-sub tracking parameters
Parameter Description
Type
Select a type according to the number of sheye and PTZ cameras:
●
1 Fisheye + 1 PTZ.
●
1 Fisheye + 2 PTZ.
●
1 Fisheye + 3 PTZ.
Scene Name Customize the scene name.
Main Camera
Select a sheye camera.
i. Click Select in Main Camera line.
ii. Select a sheye camera.
iii. Click Apply.
Sub Camera
Select speed domes as needed.
i. Click Select in Sub Camera line.
ii. Select speed domes.
iii. Click Apply.
Step 3 Click Apply.
The monitoring area is successfully added.
Step 4 Congure calibration points to set the binding relationship of sheye camera and speed
dome.
Set a distant place as the rst calibration point to improve accuracy.
1. Click or double-click the target scene.
2. Click the target place on the video of sheye camera, or move
to the target place.
The video at upper-left corner is the sheye camera screen, and the video at upper-
right corner is the speed dome screen.
3. Adjust position through the icons below the speed dome screen to make the center of
speed dome identical to the
of sheye camera.
The
on the speed dome screen is the center of speed dome.
Table 5-49 Icon description
Icon
Description
,
Zoom in and zoom out.
,
Adjust resolution.
,
Adjust height.
User's Manual
290
