Figure 5-213 UPnP
Step 2 Congure the settings for the UPnP parameters.
Table 5-62 UPnP parameters
Parameter
Description
Port Mapping Enable the UPnP function.
Status
Indicates the status of UPnP function.
●
Oine: Failed.
●
Online: Succeeded.
LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address automatically.
WAN IP
Enter IP address of router on the WAN.
After mapping succeeded, the system obtains IP address automatically.
Port Mapping
List
The settings on port mapping list correspond to the UPnP port mapping list on
the router.
●
Service Name: Name of network server.
●
Protocol: Type of protocol.
●
Internal Port: Internal port that is mapped on the Device.
●
External Port: External port that is mapped on the router.
User's Manual
330
