3.3 Remote Controller <BRC1C62> 67
Remote Controllers
18.Temperature setting button
Use this button for setting the desired temperature.
19.Filter sign reset button
Refer to the operation manual of indoor unit.
20.Fan speed control button
Press this button to select the fan speed of your preference.
21.Operation mode selector button
Press this button to select the operation mode of your preference.
22.Air flow direction adjust button
Refer to the chapter “Operation procedure - Adjusting the air flow direction”.
23.Thermistor
It sense the room temperature around the remote controller.
24.These button are used when the ventilation unit are installed (These are optional accessories)
Refer to the operation manual of the ventilation unit.
NOTE
Figure shows the remote controller which is opened the cover.
For FXS, FXM, FXL and FXN, the air flow direction ajust button (22) is not available and the display (4) shows “NOT
AVAILABLE” when pressed.
