9.7.2 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC
Table 49: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC
Nominal ratings Low overload High overload Typical motor
power, 400 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3N05-206A FE9 203 211 289 199 206 164 170 110 90
iC7-60EA3N05-245A FE9 241 251 351 236 245 199 206 132 110
iC7-60EA3N05-302A FE9 297 309 417 291 302 236 245 160 132
iC7-60EA3N05-385A FE9 379 394 514 371 385 291 302 200 160
iC7-60EA3N05-480A FE10 472 490 655 463 480 371 385 250 200
iC7-60EA3N05-588A FE10 578 601 816 567 588 463 480 315 250
9.7.3 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC
Table 50: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC
Nominal ratings Low overload High overload Typical motor
power, 480 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[Hp]
P
H
[Hp]
iC7-60EA3N05-206A FE9 185 201 283 196 206 154 166 150 125
iC7-60EA3N05-245A FE9 227 245 334 240 245 181 196 200 150
iC7-60EA3N05-302A FE9 285 309 408 302 302 222 240 250 200
iC7-60EA3N05-385A FE9 343 372 514 364 385 279 302 300 250
iC7-60EA3N05-480A FE10 430 466 619 456 480 336 364 350 300
iC7-60EA3N05-588A FE10 490 531 776 520 588 421 456 450 350
9.7.4 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC
Table 51: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC
Nominal ratings Low overload High overload Typical motor
power, 500 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3N05-206A FE9 193 201 283 189 196 160 166 132 110
iC7-60EA3N05-245A FE9 236 245 334 232 240 189 196 160 132
iC7-60EA3N05-302A FE9 297 309 408 291 302 232 240 200 160
