4.5 Description of the Model Code
The model code is made of standard codes and plus codes. Each part of the model code agrees to the data in the order.
Example
The model code can have this format, for example:
iC7-60EA3A05-880AE21F3+XXXX
Table 6: Description of the Model Code
Code Description
iC7-60 Product group
EA Product category
EA = air-cooled enclosed drive
3A Product type
3N = 3-phase 6-pulse
3A = 3-phase AFE (regenerative)
3H = 3-phase LHD (low-harmonic)
05 Voltage rating
05 = 380–500 V AC
-880A Current rating (I
L(1/5)
)
-880A = 880 A
-1260 = 1260 A
E21 Protection rating
E21 = IP21/UL type 1
E54 = IP54/UL type 12
F3 EMC level
F3 = C3 industry compliance
F4 = C4 system component
+XXXX Options
See separate list.
4.6 Product Label
The product label gives information about the product.
26 | Danfoss Drives Oy © 2024.09 AJ389643274589en-000101 / 172F6409A
Design Guide | iC7-Automation Air-cooled Enclosed Drives Product Overview
