9.7.10 Current Ratings for Low-harmonic AFE, 500 V AC
Table 57: Current Ratings for Low-harmonic AFE, 500 V AC
Nominal ratings Low overload High overload Typical motor
power, 500 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3H05-385A AE10+IE10 322 372 510 315 364 254 300 250 200
iC7-60EA3H05-480A AE10+IE10 406 466 619 397 456 315 364 315 250
iC7-60EA3H05-590A AE10+IE10 457 531 776 447 520 397 456 355 315
iC7-60EA3H05-658A AE11+IE11 518 603 833 506 590 399 490 400 315
iC7-60EA3H05-730A AE11+IE11 583 672 930 570 658 450 547 450 355
iC7-60EA3H05-820A AE11+IE11 647 746 1031 633 730 506 606 500 400
iC7-60EA3H05-880A AE11+IE11 725 838 1158 709 820 570 681 560 450
iC7-60EA3H05-1000 2 x AE10+2 x
IE10
815 940 1299 797 920 633 764 630 500
iC7-60EA3H05-1100 2 x AE10+2 x
IE10
919 1052 1454 899 1030 709 855 710 560
iC7-60EA3H05-1260 2 x AE11+2 x
IE11
1034 1174 1632 1012 1150 797 960 800 630
iC7-60EA3H05-1450 2 x AE11+2 x
IE11
1164 1328 1836 1139 1300 899 1080 900 710
iC7-60EA3H05-1710 2 x AE11+2 x
IE11
1422 1603 2227 1392 1570 1012 1310 1100 800
9.8 Technical Data
9.8.1 Mains Connections
Table 58: Mains Connections
Item Technical data
Nominal AC voltage Voltage class 5: 3 x 380...500 VAC ±10%, -15% at reduced power
Mains network TN-S, TN-C, IT and TT. (Supply voltage limited to 500 V AC for corner-grounded net-
works.)
Mains frequency 45...66 Hz
Voltage imbalance 3% of rated voltage
Short-circuit current rating, with the spec-
ified fuses
The maximum short circuit current I
cc
≤ 65 kA
True power factor (λ) ≥ 0.9 nominal at rated load
Danfoss Drives Oy © 2024.09 AJ389643274589en-000101 / 172F6409A | 125
