Danfoss iC7-Automation - Dimensions of the Enclosed Drive, FE10

9.2.2 Dimensions of the Enclosed Drive, FE10
608
(23.93)
49
(1.93)
510
(20.1)
e30bj465.11
2 x Ø11 x 21
(0.078 x Ø0.43 x 0.82)
Ø13 x 23 (Ø51 x 0.9)
20
(0.78)
20
(0.78)
2237
(88.01)
2202
535
(21.06)
684
(26.92)
657
(25.86)
25
(0.98)
2305
(90.74)
(86.69)
200
(7.87)
733
(28.85)
Figure 53: Dimensions of the Enclosed Drive, FE10, in mm (in)
78 | Danfoss Drives Oy © 2024.09 AJ389643274589en-000101 / 172F6409A
Design Guide | iC7-Automation Air-cooled Enclosed Drives Specifications
