Danfoss iC7-Automation - Current Ratings for Low-Harmonic AFE, UL, 460 V AC

Table 55: Current Ratings for Low-harmonic AFE, 400 V AC (continued)
Nominal ratings Low overload High overload Typical motor
power, 400 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3H05-1450 2 x AE11+2 x
IE11
1293 1481 2057 1265 1450 997 1210 800 630
iC7-60EA3H05-1710 2 x AE11+2 x
IE11
1453 1746 2414 1423 1710 1123 1420 900 710
9.7.9 Current Ratings for Low-harmonic AFE, UL, 460 V AC
Table 56: Current Ratings for Low-harmonic AFE, UL, 460 V AC
Nominal ratings Low overload High overload Typical motor
power, 480 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[Hp]
P
H
[Hp]
iC7-60EA3H05-385A AE10+IE10 303 372 510 296 364 247 300 300 250
iC7-60EA3H05-480A AE10+IE10 352 466 619 344 456 296 364 350 300
iC7-60EA3H05-590A AE10+IE10 451 531 776 441 520 344 456 450 350
iC7-60EA3H05-658A AE11+IE11 500 603 833 489 590 344 490 500 350
iC7-60EA3H05-730A AE11+IE11 554 672 930 542 658 443 547 550 450
iC7-60EA3H05-820A AE11+IE11 604 746 1031 591 730 492 606 600 500
iC7-60EA3H05-880A AE11+IE11 704 838 1158 688 820 542 681 700 550
iC7-60EA3H05-1000 2 x AE10+2 x
IE10
755 940 1299 738 920 591 764 750 600
iC7-60EA3H05-1100 2 x AE10+2 x
IE10
855 1052 1454 837 1030 640 855 850 650
iC7-60EA3H05-1260 2 x AE11+2 x
IE11
955 1174 1632 935 1150 738 960 950 750
iC7-60EA3H05-1450 2 x AE11+2 x
IE11
1106 1328 1836 1082 1300 837 1080 1100 850
iC7-60EA3H05-1710 2 x AE11+2 x
IE11
1306 1603 2227 1279 1570 1082 1310 1300 1100
