9.7.6 Current Ratings for Regenerative AFE, UL, 460 V AC
Table 53: Current Ratings for Regenerative AFE, UL, 460 V AC
Nominal ratings Low overload High overload Typical motor
power, 480 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[Hp]
P
H
[Hp]
iC7-60EA3A05-385A AE10+IE10 303 372 510 296 364 247 300 300 250
iC7-60EA3A05-480A AE10+IE10 352 466 619 344 456 296 364 350 300
iC7-60EA3A05-590A AE10+IE10 451 531 776 441 520 344 456 450 350
iC7-60EA3A05-658A AE11+IE11 500 603 833 489 590 344 490 500 350
iC7-60EA3A05-730A AE11+IE11 554 672 930 542 658 443 547 550 450
iC7-60EA3A05-820A AE11+IE11 604 746 1031 591 730 492 606 600 500
iC7-60EA3A05-880A AE11+IE11 704 838 1158 688 820 542 681 700 550
iC7-60EA3A05-1000 2 x AE10+2 x
IE10
755 940 1299 738 920 591 764 750 600
iC7-60EA3A05-1100 2 x AE10+2 x
IE10
855 1052 1454 837 1030 640 855 850 650
iC7-60EA3A05-1260 2 x AE11+2 x
IE11
955 1174 1632 935 1150 738 960 950 750
iC7-60EA3A05-1450 2 x AE11+2 x
IE11
1106 1328 1836 1082 1300 837 1080 1100 850
iC7-60EA3A05-1710 2 x AE11+2 x
IE11
1306 1603 2227 1279 1570 1082 1310 1300 1100
9.7.7 Current Ratings for Regenerative AFE, 500 V AC
Table 54: Current Ratings for Regenerative AFE, 500 V AC
Nominal ratings Low overload High overload Typical motor
power, 500 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3A05-385A AE10+IE10 322 372 510 315 364 254 300 250 200
iC7-60EA3A05-480A AE10+IE10 406 466 619 397 456 315 364 315 250
iC7-60EA3A05-590A AE10+IE10 457 531 776 447 520 397 456 355 315
iC7-60EA3A05-658A AE11+IE11 518 603 833 506 590 399 490 400 315
iC7-60EA3A05-730A AE11+IE11 583 672 930 570 658 450 547 450 355
iC7-60EA3A05-820A AE11+IE11 647 746 1031 633 730 506 606 500 400
