Design Guide | iC7-Automation Air-cooled Enclosed Drives Specifications
Table 51: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC (continued)
Nominal ratings Low overload High overload Typical motor
power, 500 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3N05-385A FE9 358 372 514 351 364 291 302 250 200
iC7-60EA3N05-480A FE10 449 466 619 440 456 351 364 315 250
iC7-60EA3N05-588A FE10 512 531 776 501 520 440 456 355 315
9.7.5 Current Ratings for Regenerative AFE, 400 V AC
Table 52: Current Ratings for Regenerative AFE, 400 V AC
Nominal ratings Low overload High overload Typical motor
power, 400 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3A05-385A AE10+IE10 325 394 510 317 385 254 300 200 160
iC7-60EA3A05-480A AE10+IE10 403 490 655 394 480 317 385 250 200
iC7-60EA3A05-590A AE10+IE10 508 601 816 497 588 394 480 315 250
iC7-60EA3A05-658A AE11+IE11 571 672 930 559 658 394 547 355 250
iC7-60EA3A05-730A AE11+IE11 647 746 1031 633 730 499 606 400 315
iC7-60EA3A05-820A AE11+IE11 728 838 1158 712 820 562 681 450 355
iC7-60EA3A05-880A AE11+IE11 809 899 1243 791 880 633 731 500 400
iC7-60EA3A05-1000 2 x AE10+2 x
IE10
905 1021 1411 886 1000 712 830 560 450
iC7-60EA3A05-1100 2 x AE10+2 x
IE10
1018 1123 1553 997 1100 791 913 630 500
iC7-60EA3A05-1260 2 x AE11+2 x
IE11
1148 1287 1785 1123 1260 886 1050 710 560
iC7-60EA3A05-1450 2 x AE11+2 x
IE11
1293 1481 2057 1265 1450 997 1210 800 630
iC7-60EA3A05-1710 2 x AE11+2 x
IE11
1453 1746 2414 1423 1710 1123 1420 900 710
