Danfoss iC7-Automation - Current Ratings for Low-Harmonic AFE, 400 V AC

Design Guide | iC7-Automation Air-cooled Enclosed Drives Specifications
Table 54: Current Ratings for Regenerative AFE, 500 V AC (continued)
Nominal ratings Low overload High overload Typical motor
power, 500 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3A05-880A AE11+IE11 725 838 1158 709 820 570 681 560 450
iC7-60EA3A05-1000 2 x AE10+2 x
IE10
815 940 1299 797 920 633 764 630 500
iC7-60EA3A05-1100 2 x AE10+2 x
IE10
919 1052 1454 899 1030 709 855 710 560
iC7-60EA3A05-1260 2 x AE11+2 x
IE11
1034 1174 1632 1012 1150 797 960 800 630
iC7-60EA3A05-1450 2 x AE11+2 x
IE11
1164 1328 1836 1139 1300 899 1080 900 710
iC7-60EA3A05-1710 2 x AE11+2 x
IE11
1422 1603 2227 1392 1570 1012 1310 1100 800
9.7.8 Current Ratings for Low-harmonic AFE, 400 V AC
Table 55: Current Ratings for Low-harmonic AFE, 400 V AC
Nominal ratings Low overload High overload Typical motor
power, 400 V AC
Model code Frame
I
N-in
[A] I
N
[A] I
peak
[A]
I
L-in
[A] I
L
[A] I
H-in
[A] I
H
[A] P
L
[kW]
P
H
[kW]
iC7-60EA3H05-385A AE10+IE10 325 394 510 317 385 254 300 200 160
iC7-60EA3H05-480A AE10+IE10 403 490 655 394 480 317 385 250 200
iC7-60EA3H05-590A AE10+IE10 508 601 816 497 588 394 480 315 250
iC7-60EA3H05-658A AE11+IE11 571 672 930 559 658 394 547 355 250
iC7-60EA3H05-730A AE11+IE11 647 746 1031 633 730 499 606 400 315
iC7-60EA3H05-820A AE11+IE11 728 838 1158 712 820 562 681 450 355
iC7-60EA3H05-880A AE11+IE11 809 899 1243 791 880 633 731 500 400
iC7-60EA3H05-1000 2 x AE10+2 x
IE10
905 1021 1411 886 1000 712 830 560 450
iC7-60EA3H05-1100 2 x AE10+2 x
IE10
1018 1123 1553 997 1100 791 913 630 500
iC7-60EA3H05-1260 2 x AE11+2 x
IE11
1148 1287 1785 1123 1260 886 1050 710 560
