9.2.15 Dimensions of an Option Board
61.8
(2.43)
133.5
(5.25)
1
(0.04)
Ø4
(0.16)
126.4
(4.98)
20.15
(0.79)
150.3
(5.92)
e30bi580.11
9.8
(0.38)
Ø4.8
(0.19)
4.5
(0.18)
Figure 66: Dimensions of an Option Board in mm (in)
