9.2.17 Dimensions of the 8-port Star Coupler Board
63.6
(2.50)
19.8
(0.78)
e30bm029.10
8
(0.32)
187.5
(7.38)
196
(7.72)
4
(0.16)
Ø4.8
(Ø0.19)
Figure 68: Dimensions of the 8-port Star Coupler Board in mm (in)
