Design Guide | iC7-Automation Air-cooled Enclosed Drives Product Overview
11 Control cable grommet, top A View from the top
B View from the bottom
9
10
B
A
e30bj471.11
14
1
2
3
4
5
6
7
7
12
7
8
8
13
11
15
Figure 4: Interior View of FE10 with Top-entry Option
1 Control compartment 2 Contactor (behind control compartment)
3 Main switch (optional) 4 Mains terminals
5 dU/dt Filter 6 Motor terminals
7 PE busbar 8 Inlet air grill
9 IP54 grommet for mains and motor cables (IEC) 10 Control cable grommet, bottom
11 Motor terminals (behind PE busbar, Top-entry option) 12 Mains terminals (Top-entry option)
13 Brake terminals (Top-entry option) 14 Control cable grommet, top
Danfoss Drives Oy © 2024.09 AJ389643274589en-000101 / 172F6409A | 19
