Design Guide | iC7-Automation Air-cooled Enclosed Drives Product Overview
1 Control compartment 2 Contactor
3 Main switch 4 AC fuses
5 Motor fan control/supply terminals (+ICFI1-4), AUX AC
supply terminals (+IHAS), motor heater supply (+IAMH)
6 PE busbar
7 Inlet air grill 8 Control cable grommet, top
9 DC fuses, behind the touch protection plate 10 Motor terminals
11 Mains terminals 12 Control cable grommet, bottom
13 IP54 grommet for mains and motor cables (IEC)
