See the pin numbering of the I/O and Relay Option in 7.6 I/O and Relay Option Connectionsand the pin numbering of the
terminal blocks in 7.4 Control Compartment Connections.
e30bj921.11
1
2
Figure 45: Example of Installing the Control Cables on the Option Board
1 Control cable 2 Cable clamp
