Table 31: Dimensions in mm (in)
Product D DD W W1 W2 W3 W4 W5
iC7-60EA3A05-385...590
A
671 (26.4) 1385
(54.5)
800 (31.5) 800 (31.5) – – – 400 (15.7)
iC7-60EA3A05-658...880
A
679 (26.7) 1385
(54.5)
1200
(47.2)
400 (15.7) 800 (31.5) – – 400 (15.7)
iC7-60EA3A05-1000...11
00
679 (26.7) 1185
(46.7)
2200
(86.6)
400 (15.7) 600 (23.6) 600 (23.6) 600 (23.6) 400 (15.7)
iC7-60EA3A05-1260...17
10
671 (26.4) 1185
(46.7)
2400
(94.5)
600 (23.6) 600 (23.6) 600 (23.6) 600 (23.6) 400 (15.7)
