Technical item or function
Technical data
Altitude
100% load capacity (no derating) up to 1000 m 1-% derating for
each 100 m above 1000; maximum 3000 m (690 V max 2000 m).
Vibration: EN50178/EN60068-2-6
Displacement amplitude 0.25 mm (peak) at 5–31 Hz Max acceler-
ation 1 G at 31–150 Hz. Use anti-vibration mountings under the
drive if extra vibration resistance is required.
Shock: EN50178, EN60068-2-27
UPS Drop Test (for applicable UPS weights) Storage and shipping:
max 15 G, 11 ms (in package)
Protection rating
IP21/NEMA1 standard in entire kW/HP range IP54/NEMA12 op-
tion in entire kW/HP range.
Pollution degree
PD3
EMC (at default set-
tings)
Immunity
Fulfills all EMC immunity requirements
Emissions
EMC level L: EN 61800-3 (2004), Category C3 EMC level T: Low
earth-current solution for IT-networks, EN 61800-3 (2004), Cate-
gory C4 (can be modified from level L units.
Noise level
Average noise level (cooling fan) in
dB(A)
The sound pressure depends on the cooling fan speed, which is
controlled in accordance with the drive temperature.
FR8: 58
FR9–FR13: 76
FR14: 78
Functional safety
Hardware based ‘Safe Torque Off’
safety function to prevent the drive
from generating torque on the motor
shaft.
STO safety function has been de-
signed for use in accordance with the
following standards
EN 61800-5-2 Safe Torque Off (STO) SIL3
EN ISO 13849-1 PL “e” Category 3
EN 62061 SILCL3
IEC 61508 SIL3
The function also corresponds to an uncontrolled stop in ac-
cordance with stop category 0, EN 60204-1.
EN 954-1, Category 3
SS1 safety function is realized in com-
pliance with type C of the drives safe-
ty standard EN61800-5-2 (Type C:
“The PDS(SR) initiates the motor de-
celeration and initiates the STO func-
tion after an application specific time
delay”). SS1 safety function has been
designed for use in accordance with
the following standards:
EN 61800-5-2 Safe Stop 1 (SS1) SIL3
EN ISO 13849-1 PL "e" Category 3
EN 62061 SILCL3
IEC 61508 SIL3
The function also corresponds to a controlled stop in accord-
ance with stop category 1, EN60204-1.
ATEX thermistor input
2014/34/EU, CE 0537 Ex 11 (2) GD
Approvals
-
EN 50178 (1997), EN 60204-1 (1996), EN 60950 (2000, 3rd edition)
(as relevant), CE, UL, CUL, EN 61800-5; (see unit nameplate for
more detailed approvals). IEC 60664-1 and UL840 in overvoltage
category III.
Efficiency
-
See http://ecosmart.danfoss.com/
Control connections
(factory default I/O)
Analog input voltage
0…+10 V, R
i
= 200 kW, (–10 V…+10 V joystick control) Resolution
0.1%, accuracy ±1%
AQ351737303996en-000201 / DPD00888148 | Danfoss A/S © 2023.09
Specifications
VACON® NXP IP00 Drive Modules
Operating Guide
