Enter/Exit Programming Mode
234
PowerScan™ PD9330/PBT9300/PM9300
CONFIGURE ACTIONS FOR FUNCTION KEYS
Each of the function keys can be programmed to perform a user-assigned
function. This is done by associating a function key with either a predefined
command or your own custom string. See the "Defin
e Strings" on page
238command to define customized strings.
Each function key has an associated label
which shows in the display when
active. The default labels are shown in the table below. To program the
function key labels, see "Set S
tring ID" on page 239.
The following table shows the list of predefined commands and available
st
rings.
Table 30. Keyboard Programming
CMD_ID Name Function
Default
Label
16K 4K
0 Not configured
Not configured action.
If a key must be kept enabled but isn’t required
in normal mode , this function can be selected to
keep it ineffective. Whenever an unconfigured
function key is pressed, an error message
appears on the display and an error beep is
emitted.
<None>
1 Enter CMD Same as ENTER_KEY. Ent
2 String 1 Display and transmit string 1. S1T
3 String 2 Display and transmit string 2. S2T
4 String 3 Display and transmit string 3. S3T
5 String 4 Display and transmit string 4. S4T
6 String 5 Display and transmit string 5. S5T
7 Backlight CMD Toggle backlight on/off. Blt
8 Clear CMD Clears the screen CLR
9 Backspace CMD Same as Backspace key.
A Recall
If pressed once, it recalls the last code sent out.
If pressed twice, resends the last code.
Rcl
B Show Date/Time Display the internal date, time. Tim
C Scroll Up Scroll up display content by row
Up
D Scroll Down Scroll down display content by row
Dwn
E Dot char Display dot [.] char [.]
F
Dynamic
Quantity
Dynamic Quantity Code function Qty
