Technical Specifications
294
PowerScan™ PD9330/PBT9300/PM9300
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate various func-
tions or errors on the reader. An optional “Green Spot” also performs useful
f
unctions. The tables below list these indications. One exception to the
behaviors listed in the tables is that the reader’s functions are programma-
ble, and may or may not be turned on. For example, certain indications such
as the
power-up beep can be disabled using programming bar code labels.
Table 50.
INDICATION DESCRIPTION LED BEEPER
Power-up
Beep
The reader is in the pro-
cess of powering-up.
Reader beeps four
tim
es at highest fre-
quency and volume
upon power-
up.
Good Read
Beep
A label has been suc-
cessfully scanned by
the
reader.
LED behavior for
t
his indication is
configurable via
the feature “
Good
Read: When to
Indicate
”
The reader will beep
once at current
fre-
quency, volume, tonal
se
tting and duration
upon a successful label
scan.
Green Spot
a
a. Except when in sleep mode or when a
Good Read LED Duration
other than 00 is selected
flashes
momentar
ily
Upon successful read of
a label,
the software
turns the green spot on
for the time specified by
the configured value.
N/A N/A
LED and Beeper Indications
Table 51. Programming Mode Indications
Programming Mode
- The following indications ONLY occur when the reader is in Pro-
gramming Mode.
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Entry
A valid programming
label has been scanned.
LED blinks con-
tinuously
Reader sounds
four low
frequency
beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been rejected. N/A
Reader sounds
t
hree times at low-
est frequency &
curr
ent volume.
Label Program-
ming Mode Accep-
tance of Partial
Labe
l
In cases where multiple
labels must be scanned
to pr
ogram one feature,
this indication acknowl-
edges each portion as it is
succe
ssfully scanned.
N/A
Reader sounds one
shor
t beep at high-
est frequency &
curr
ent volume.
Programming Mode Indications (continued)
INDICATION DESCRIPTION LED BEEPER
