Datalogic PD9330 User Manual

Product Reference Guide 287
Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 49 provides Standard
Cable Pinouts.
Table 48. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable)
PD9330: 340g; PD9330-AR: 375g
PM/PBT9300-XX: 405g; PM/PBT9300-ARXX,
PM/PBT9300-DXX, PM/PBT9300-DKXX: 435g;
PM/PBT9300-DARXX, PM/PBT9300-DKARXX: 465g
Electrical Characteristics
PD9330 models
Voltage & Current PD9330 PD9330-AR
Input Voltage 4.5 / 30 VDC 4.5 / 30 VDC
Input Current
Operating (typical, scan-
ning)
110 mA @ 4.5 V
105 mA @ 5 V
45 mA @ 12 V
25 mA @ 30 V
180 mA @ 4.5 V
170 mA @ 5 V
70 mA @ 12 V
40 mA @ 30 V
Operating (max, reading)
420 mA @ 4.5 V
360 mA @ 5 V
140 mA @ 12 V
65 mA @ 30 V
480 mA @ 4.5 V
420 mA @ 5 V
160 mA @ 12 V
80 mA @ 30 V
Idle/Standby (typical)
45 mA @ 4.5 V
40 mA @ 5 V
20 mA @ 12 V
12 mA @ 30 V
45 mA @ 4.5 V
40 mA @ 5 V
20 mA @ 12 V
12 mA @ 30 V
