Installing Printer Drivers on the Windows Computers 117
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_AIO_UG_FM\Mioga_AIO_UG_FM\section10.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .
10 To change the printer name, enter the printer name in the Printer name box,
and then click
Next .
To use this printer as the default printer, select the
Set as the default printer
check box, and then click
Next .
11 If you do not share your printer, select Do not share this printer . If you
share your printer, select
Share this printer so that others on your network
can find and use it
.
12 Click Next .
Installation starts.
13 As the driver installation is completed, click Print a test page to print a test
page.
14 Click Finish .
Windows 7, Windows 7 64-bit Edition, or Windows Server 2008 R2
1
Extract the following zip file to your desired location.
D:\Drivers\XPS\Win_7Vista\XPS_2155.zip (where D is the
CD drive letter)
2 Click Start  Devices and Printers .
3 Click Add a printer .
When you use Windows Server 2008 R2, click
Add a local or network
printer as an administrator
.
If the
User Account Control dialog box appears, click Ye s .
NOTE: If you are an administrator on the computer, click Yes ; otherwise,
contact your administrator to continue the desired action.
4 Click Add a local printer .
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
