Pitched color dots
Action Yes No
1 Ensure Output Color is set to Color (Auto) in
the printer driver.
a On the Graphics tab, ensure that the Output
Color is set to Color (Auto) .
Does this solve your problem?
The task is
complete.
Go to action 2.
2 Replace the PHD unit if you have a spare unit.
a Replace the PHD unit. See "Replacing the
Print Head Device (PHD) Unit" and
"Installing a PHD Unit."
b After you replace the PHD unit, click Chart
Print
on the Diagnosis tab.
c Click the 4 Colors Configuration Chart
button.
The 4 Colors Configuration Chart is printed.
Does this solve your problem?
The task is
complete.
Contact Dell.
