213
Code Value (bit 8 = 1,
bits 11:4 shown below)
Module Display
15:
12
11
:8
7:
4
3:
0
8 F 2 0 Pass1 Entry
8 F 2 1 Process Auto Scan Input
8 F 2 2 Execute Auto scan (C- code)
8 F 2 3 Process Auto Scan Output
0xF1 Recovery stackless North
0xF0 Reserved North
0xEF-0xEE Memory Autoscan C-code North
0xED-E8 Recovery C-Code
0xE7-0xE6 HOB North
0xE5-0xC1 Reserved North
0xC0 SALA to SALB/DXE handoff North
0xB0-0xBF Reserved North
0xAF-80 Reserved for SAL MCA, INIT, PMI North
0x7F to 0x60 SAL-B codes
SAL-B
SAL_C
SAL_F
South
South
South
0x60 SAL to EFI handoff South
0x5F to 0x50 EFI South
0x4F to 0x40 ACPI South
