78
2. Select the Function0 LSI Logic Ultra320 SCSI Controller’s serial number and press <Enter>.
The Main menu appears in Figure 18.
LSI Logic MPT SCSI Setup Utility Version v1.00.04.00
LSI Logic Host Bus Adapters
Adapter PCI PCI PCI Rev FW MPI Product LSI Mirror
Bus Dev Func ID Rev Rev Control Status
<53C1030 06 02 00 > 07 01000000 0102 Basic Enabled --
F1/Shift+1 =Help Arrow Keys/H,J,K,L =Select Item +/- = Change [Item]
Esc = Abort/Exit Home (I)/End (O) = Select Item Enter = Execute [Item]
Figure 18. LSI SCSI Utility Main Menu
3. Use the arrow keys to highlight the adapter that needs to be configured and press <Enter>. The
screen clears and the following message is displayed:
Scanning for devices…
4. Make any changes necessary, using the screens shown in Figures 19, 20, and 21.
