33
Internal Chassis Features
WARNING
Only qualified technical personnel should access any internal system
component. Some exposed circuits exceed 240 VA and may cause injury
if accidentally contacted.
Electronics Bay
The electronics bay, shown in Figures 11 and 12, consists of the following:
• Main board
• PCI riser board
• Two processor locations and two power pod locations
• Eight DIMM slots
• Air duct for the processor area
• PCI riser bracket to support PCI riser board and PCI cards
• Connectors, switches and LEDs at the rear of the chassis (see Figure 10)
Figure 11. Electronics Bay
