144 | Aruba Configuration Reference AirWave Wireless Management Suite | Configuration Guide
Click Add to complete the configuration of the BW Contract profile, or click Save to complete the editing of
an existing profile. The new BW contract appears on the
Security > User Roles page.
Security > User Roles > VPN Dialers
The VPN dialer can be downloaded using Captive Portal. For the user role assigned through Captive Portal,
configure the dialer by the name used to identify the dialer. For example, if the captive portal client is
assigned the guest role after logging on through captive portal and the dialer is called
mydialer, configure
mydialer as the dialer to be used in the guest role.
Select a dialer from the drop-down list and assign it to the user role. This dialer will be available for
download when a client logs in using captive portal and is assigned this role.
The
Security > User Roles > Add New VPN Dialer page contains the following fields, as described in Table 58:
Name Blank Enter the name of the profile.
Other Settings
Units kbits Configure bandwidth contracts, in kilobits per second (Kbps) or megabits
per second (Mbps), for the following types of traffic:
z from the client to the controller (“upstream” traffic)
z from the controller to the client (“downstream” traffic)
Bandwidth N/A Specify whether this bandwidth contract is upstream or downstream by
typing one of the following terms in lower case:
z upstream
z downstream
Click Add to finish the new BW Contract and to return to the BW Contract
page. The new contact appears below the Add New BW Contract button.
Table 58 Security > User Roles > Add VPN Dialer Field Descriptions
Field Default Description
General Settings
Folder Top Use this field to set and display the folder with which the VPN Dialer is
associated. The drop-down menu displays all folders available for
association with the profile.
Name Blank Enter the name of the profile.
Other Settings
Enable PPTP No Enable PPTP with this setting as desired.
Point-to-Point Tunneling Protocol (PPTP) is an alternative to L2TP/IPSec.
Like L2TP/IPSec, PPTP provides a logical transport mechanism to send PPP
frames as well as tunneling or encapsulation so that the PPP frames can be
sent across an IP network. PPTP relies on the PPP connection process to
perform user authentication and protocol configuration.
With PPTP, data encryption begins after PPP authentication and connection
process is completed. PPTP connections use Microsoft Point-to-Point
Encryption (MPPE), which uses the Rivest-Shamir-Aldeman (RSA) RC-4
encryption algorithm. PPTP connections require user-level authentication
through a PPP-based authentication protocol (MSCHAPv2) is the currently-
supported method).
Table 57 Security > User Roles > Add New BW Contract Page Field Descriptions (Continued)
Field Default Description
