Dell PowerConnect W-Airwave - Profiles AP AP Wired

88 | Aruba Configuration Reference AirWave Wireless Management Suite | Configuration Guide
3. Click Add or Save. The added or edited Regulatory Domain profile appears on the Regulatory Domain
Profiles
page.
Profiles > AP > AP Wired
The wired AP profile controls the configuration of the Ethernet port(s) on your AP. You can use the wired
AP profile to configure Ethernet ports for bridging or secure jack operation using the wired AP profile.
Perform these steps to configure a
Wired AP profile.
1. Click
Profiles > AP > Wired in the Aruba Navigation pane. This page summarizes the current profiles of
this type.
2. Click the
Add button to create a new Wired profile, or click the pencil icon next to an existing profile to
edit that profile. The
Details page appears. Complete the settings as described in Table 22:
Valid 802.11g 40
MHz Channel Pairs
N/A Select a 40MHz channel pair for 802.11ag
A high-throughput (HT) AP can use a 40 MHz channel pair comprised of
two adjacent 20 MHz channels available in the regulatory domain profile
for your country. When ARM is configured for a dual-band AP, it will
dynamically select the primary and secondary channels for these
devices. It can, however, continue to scan all changes in the a+b/g
bands to calculate interference and detect rogue APs.
Valid 802.11a
40MHz Channels
N/A Specify the valid channels for 40MHz channel pairing in 802.11a.
Valid 802.11g 40
MHz Channels
N/A Specify the valid channels for 40MHz channel pairing in 802.11g.
Table 22 Aruba Configuration > Profiles > AP > Wired Profile Settings
Field Default Description
General Settings
Folder Top Use this field to set and display the folder with which the profile is
associated. The drop-down menu displays all folders available for
association with the profile.
Folders provide a way to organize the visibility of device parameters
that is separate from the configuration groups of devices. Using
folders, you can view basic statistics about device, and define which
users have visibility to which device parameters.
Name Blank Enter the name of the profile.
Other Settings
Wired AP Enable No Designate whether Wired APs are to be enabled or disabled.
Forward Mode tunnel If Wired AP is enabled, designate whether forwarding is to be bridge-
based or tunnel-based.
Table 21 Aruba Configuration > Profiles > AP > Regulatory Domain Profile Settings
Field Default Description
