AirWave Wireless Management Suite | Configuration Guide Aruba Configuration Reference | 89
3. Click Add or Save. The added or edited 802.1x Auth profile appears on the AAA Profiles page, and on the
802.1x Auth details page.
Switchport Mode Access Select access or trunk. These options only apply to bridge mode
configurations.
z Access mode forwards untagged packets received on the port to
the controller and they appear on the configured access mode
VLAN. Tagged packets are dropped. All packets received from the
controller and sent via this port are untagged. Define the access
mode VLAN in the Access mode VLAN field.
z Trunk mode contains a list of allowed VLANs. Any packet
received on the port that is tagged with an allowed VLAN is
forwarded to the controller. Untagged packets are forwarded to
the controller on the configured Native VLAN. Packets received
from the controller and sent out the port remain tagged unless the
tag value in the packet is the Native VLAN, in which case the tag is
removed. Define the Native VLAN in the Trunk mode native VLAN
field and the other allowed VLANs in the Trunk mode allowed
VLANs field.
Access Mode VLAN
(1-4096)
1 Access mode forwards untagged packets received on the port to the
controller and they appear on the configured access mode VLAN.
Tagged packets are dropped. All packets received from the controller
and sent via this port are untagged. Define the access mode VLAN in
the Access mode VLAN field. The VLAN range is from 1 to 4096.
Trunk Mode Native
VLAN (1-4096)
1 Trunk mode contains a list of allowed VLANs. Any packet received on
the port that is tagged with an allowed VLAN is forwarded to the
controller. Untagged packets are forwarded to the controller on the
configured Native VLAN. Packets received from the controller and
sent out the port remain tagged unless the tag value in the packet is
the Native VLAN, in which case the tag is removed. Define the Native
VLAN in the Trunk mode native VLAN field and the other allowed
VLANs in the Trunk mode allowed VLANs field.
Trunk Mode
Allowed VLANs
Define whether the trunk mode settings defined in additional fields of
this profile are to allow VLANs. The VLAN range is from 1 to 4094.
Enter a list or a range of numbers. The VLAN range is from 1 to 4096.
You can enter a range of numbers, specific numbers or a combination
of range and specific VLAN numbers, as desired.
Trusted No Use this option if the wired port is a trusted port.
Broadcast Yes Use this option if the wired port is a broadcast port.
Table 22 Aruba Configuration > Profiles > AP > Wired Profile Settings
Field Default Description
