AirWave Wireless Management Suite | Configuration Guide Aruba Configuration Reference | 169
Click Add to create the PPTP profile, or click Save to preserve changes to an existing PPTP profile. The
PPTP profile appears on the
Advanced Services > VPN Services > PPTP page.
Advanced Services > VPN Services > IPSEC
The combination of Layer-2 Tunneling Protocol and Internet Protocol Security (L2TP/IPSec) is a highly
secure technology that enables VPN connections across public networks such as the Internet. L2TP/IPSec
provides both a logical transport mechanism on which to transmit PPP frames as well as tunneling or
encapsulation so that the PPP frames can be sent across an IP network. L2TP/IPSec relies on the PPP
connection process to perform user authentication and protocol configuration. With L2TP/IPSec, the user
authentication process is encrypted using the Data Encryption Standard (DES) or Triple DES (3DES)
algorithm.
L2TP/IPSec requires two levels of authentication:
z Computer-level authentication with a preshared key to create the IPSec security associations (SAs) to
protect the L2TP-encapsulated data.
z User-level authentication through a PPP-based authentication protocol using passwords, SecureID,
digital certificates, or smart cards after successful creation of the SAs.
Navigate to
Advanced Services > VPN Services > IPSEC from the Aruba Configuration navigation pane. This
page displays the IPSEC profile name, the VPN services that use the IPSEC profile, and the folder
associated with the IPSEC Profile.
Table 79 Advanced Services > VPN Services > PPTP Add/Edit Details Field Descriptions
Field Default Description
General Settings
Folder Top Use this field to set and display the folder with which the PPTP
profile is associated. The drop-down menu displays all folders
available for association with the PPTP profile.
Name Blank Enter the name of the PPTP profile.
Other Settings
Enable PPTP Yes Enable or disable this PPTP profile.
Echo Timeout
(10-300 sec)
60 Define the PPTP echo timeout, which is the time between request
and sending echo reply. Should this require more time than
specified in this field, the PPTP session times out.
PPP Authentication
MSCHAP
No Enable or disable the MSCHAP authentication protocol for this
PPTP profile.
PPP Authentication
MSCHAPv2
Yes Enable or disable the MSCHAPv2 authentication protocol for this
PPTP profile.
Primary DNS Server N/A Enter the IP address of the primary DNS server.
Secondary DNS Server N/A Enter the IP address of the secondary DNS server.
Primary WINS Server N/A Enter the IP address of the primary Windows Internet Naming
Service (WINS) server.
Secondary WINS
Server
N/A Enter the IP address of the secondary WINS server.
