AirWave Wireless Management Suite | Configuration Guide Aruba Configuration Reference | 171
Click Add to complete the creation of the Dynamic Map, or click Save to retain changes to an existing
Dynamic Map.
Advanced Services > VPN Services > IPSEC > Dynamic Map > Transform Set
VPN Services may reference IPSEC profiles. Transform sets define the encryption and hash algorithm to be
used by a dynamic map in an IPSEC profile that supports VPN Services.
Navigate to
Advanced Services > VPN Services > IPSEC > Dynamic Map > Transform Set from the Aruba
Configuration navigation pane. This page displays all currently configured Transform Sets, and which
Dynamic Maps reference them.
Click
Add to create a new Transform Set, or click the pencil icon next to an existing Transform Set to
modify settings. The
Add/Edit Details page contains the following fields, as described in Table 82:
Click
Add to create the new Transform Set, or click Save if editing an existing Transform Set. The
Transform Set is available for reference by Dynamic Maps in support of IPSEC profiles and VPN services.
Name Blank Enter the name of the Dynamic Map.
Other Settings
Priority N/A Specify the priority in which this Dynamic Map should be
processed in relation to additional Dynamic Maps that may be
configured and used by IPSEC profiles.
Perfect Forward
Secrecy Mode
None From the drop-down menu, select the Diffie-Hellman group to be
used by this dynamic map.
Lifetime
(300-86400 sec)
N/A Define the lifetime in seconds for the dynamic map, when
deployed in IPSEC profiles.
Transform Set 1-4 N/A From the drop-down menu, select up to four transform sets in the
sequence in which they should be referenced by the Dynamic
Map. You can add a new Transform Set by clicking the add icon,
or you can edit an existing Transform Set by clicking the pencil
icon. For additional information, refer to “Advanced Services >
VPN Services > IPSEC > Dynamic Map > Transform Set” on
page171.
Table 82 Advanced Services > VPN Services > IPSEC > Dynamic Map > Transform Set Add/Edit
Details Field Descriptions
Field Default Description
General Settings
Folder Top Use this field to set and display the folder with which the
Transform Set is associated. The drop-down menu displays all
folders available for association with the Transform Set.
Name Blank Enter the name of the Transform Set.
Other Settings
Encryption 168-bit 3DES-CBC Select the encryption for the transform set from the drop-down
menu.
Hash Algorithm SHA (HMAC Variant) Select the hash algorithm from the drop-down menu.
Table 81 Advanced Services > VPN Services > IPSEC > Dynamic Map Add/Edit Field Descriptions
Field Default Description
