70 | Aruba Configuration Reference AirWave Wireless Management Suite | Configuration Guide
Folder Top Use this field to set and display the folder with which the profile is
associated. The drop-down menu displays all folders available for
association with the profile.
Folders provide a way to organize the visibility of device parameters
that is separate from the configuration groups of devices. Using
folders, you can view basic statistics about device, and define which
users have visibility to which device parameters.
Name Blank Enter the name of the Captive Port Authentication profile.
Referenced Profiles
Server Group default Enter the name of the internal VPN authentication server group, or the
server group that performs 802.1x authentication.
Other Settings
Default Role default Role assigned to the Captive Portal user upon login. When both user
and guest logon are enabled, the default role applies to the user
logon; users logging in using the guest interface are assigned the
guest role. The Policy Enforcement Firewall license must be installed.
Redirect Pause
(0-60 sec)
10 Time, in seconds, that the system remains in the initial welcome page
before redirecting the user to the final web URL. If set to 0, the
welcome page displays until the user clicks on the indicated link.
User Login Yes Enables Captive Portal with authentication of user credentials.
Guest Login No Enables Captive Portal logon without authentication.
Logout Popup
Window
Yes Enables a pop-up window with the Logout link for the user to logout
after logon. If this is disabled, The user remains logged in until the
user timeout period has elapsed or the station reloads.
Use HTTP
Authentication
No Use HTTP protocol on redirection to the Captive Portal page. If you
use this option, modify the captive portal policy to allow HTTP traffic.
Logon Wait Minimum
Wait (1-10 sec)
5 Minimum time, in seconds, the user will have to wait for the logon
page to pop up if the CPU load is high. This works in conjunction with
the Logon wait CPU utilization threshold parameter.
Logon Wait
Maximum Wait
(0-10 sec)
10 Maximum time, in seconds, the user will have to wait for the logon
page to pop up if the CPU load is high. This works in conjunction with
the Logon wait CPU utilization threshold parameter.
Logon Wait CPU
Utilization Threshold
(0-100 sec)
60 CPU utilization percentage above which the Logon wait interval is
applied when presenting the user with the logon page.
Max Authentication
Failures
0 Maximum number of authentication failures before the user is
blacklisted.
Show FQDN No Allows the user to see and select the fully-qualified domain name
(FQDN) on the login page.
Use CHAP
(Non-standard)
No Use CHAP protocol. You should not use this option unless instructed
to do so by an Aruba representative.
Sygate-on-demand-
agent
No Enables client remediation with Sygate-on-demand-agent (SODA).
Login Page /auth/index.html URL of the page that appears for the user logon. This can be set to
any URL.
Welcome Page /auth/
welcome.html
URL of the page that appears after logon and before redirection to the
web URL. This can be set to any URL.
Table 11 Captive Portal Auth Profile Settings
Field Default Description
