Appendix - Fieldbus_01/2016 - 75 -
1.12 - Outputs variables
Name Description
General commands
CVI3 inputs State of the 8 controller inputs that can be forced by the PLC.
Identier Identier (e.g. VIN number) which can be used to start an assembly process
Keep alive value
Value that will be copied in Keep Alive Value Ack. Value change can be used as
heartbeat management.
User variable 1
A variable freely settable by user. No treatment is made on this value. This value is
copied in User Variable 1 Ack.
User variable 2
A variable freely settable by user. No treatment is made on this value. This value is
copied in User Variable 2 Ack.
Date synchro data
"Date synchronisation data.
Format is YYYYMMDD in ASCII."
Time synchro data
"Time synchronisation data.
Format is HHMMSS in ASCII"
Pset commands
Pset selection ID of Pset expected by PLC
Assembly Process commands
AP selection
"Id of Assembly process expected by PLC. If the Assembly process #0 is requested,
then the current assembly process is aborted.
The controller behavior can be adapted by using the “Assembly process” panel in
general conguration"
Socket tray
Socket green led as bit
Control green led of socket trays. In binary each bit is encoding one socket. In
ASCII each digit is encoding one socket. Socket tray must be in external mode.
Socket red led as bit
Control red led of socket trays. In binary each bit is encoding one socket. In ASCII
each digit is encoding one socket. Socket tray must be in external mode.
Customized protocol Status
PRG Tightening program number in range 1-255.
SIO_MNO
"SIO : number of OK on 4 bits
MNO : max number of NOK on 4 bits"
CIO_CNO
"CIO : class for OK tightenings on 4 bits
CNO : class for NOK tightenings on 4 bits"
PRT Model description.
PI1 Unique workpiece ID
STC_VAR
"STC : XML 2.0
VAR : XML 2.1"
FNR Tightening case number
TNR Tightening location number
WID Workpiece carrier-ID
PNR Pronet XML version
CVILOGIX inputs
"CVILOGIX %1
…
CVILOGIX %100"
CVILOGIX variable (1 to 100)
