Desoutter CVI3 Vision User Manual

Appendix - Fieldbus_01/2016- 74 -
Name Description ASCII values
Numerical
values or
binary format
Reset
condition
Set condition
Socket tray
Socket lifted
Socket lifted. If a socket is left on
CVI2 socket tray then sockets on
CVI3 socket tray are not considered.
Never Socket lifted
Socket lifted as bit
Socket lifted, each bit is encoding
one socket (Socket tray must be in
external mode). If a socket is left
on CVI2 socket tray then sockets on
CVI3 socket tray are not considered.
Never Socket lifted
Socket Lifted and its
address
Socket Lifted and its address (keep
last address in case no sockets are
lifted)
"DDLLL
DD : deviceID
LLL : lifted
socket (255 if
more than 1
socket)."
"Byte0 =
DeviceID
Byte1 = lifted
socket position
(255 if more
than 1 socket)."
Never Socket lifted
Customized protocol Status
Q_PRG Selected program number
IIO_INO
"IIO : number of OK on 4 bits
INO : number of OK on 4 bits"
TSC Place for status code
Q_PI1 Ack workpiece-ID
Q_FNR Receiving tightening case number
Q_TNR Receiving tightening location number
ECL Error class
ERC Error code
VEN Controller brand code
TYP Controller type code - - - -
CVILOGIX outputs
"CVILOGIX %1
….
CVILOGIX %100"
CVILOGIX variable (1 to 100) - - - -
1.11 - Events in PLC input
All output events can be associated to PLC inputs in Fieldbus.
For each event, you can choose to invert or not the signal.
