Desoutter CVI3 Vision User Manual

Appendix - Fieldbus_01/2016 - 73 -
Name Description ASCII values
Numerical
values or
binary format
Reset
condition
Set condition
Min torque rate in
N.m/° (setting)
Min torque rate in N.m/° (setting) Tight start Result received
Target torque rate in
N.m/° (setting)
Target torque rate in N.m/° (setting) Tight start Result received
Max. torque rate in
N.m/° (setting)
Max torque rate in N.m/° (setting) Tight start Result received
Final (result) torque
rate in N.m/°
Final (result) torque rate in N.m/° Tight start Result received
Torque rate trend Torque rate trend
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Yield ratio in % Yield ratio in % of N.m/°(setting) Tight start Result received
Min prevailing in N.m Min prevailing in N.m Tight start Result received
Max prevailing in N.m Max prevailing in N.m Tight start Result received
Min prevailing in N.m
(setting)
Min prevailing in N.m (setting) Tight start Result received
Max prevailing in N.m
(setting)
Max prevailing in N.m (setting) Tight start Result received
Final prevailing in N.m Final (result) prevailing in N.m Tight start Result received
Prevailing trend Prevailing trend
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Result type Type of the result.
"0 : no result
1 : tightening
2 : run-reverse"
Tight start Result received
Final torque
(monitoring
transducer)
Final torque (monitoring) in N.m. (last
step)
Tight start Result received
Torque trend
(monitoring
transducer)
Torque trend (monitoring) (last step)
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Final angle
(monitoring
transducer)
Final angle (monitoring) in degrees
(last step)
Tight start Result received
Angle trend
(monitoring
transducer)
Angle trend (monitoring) (last step)
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Result ID Result ID Tight start Result received
Step number Last executed step number Tight start Result received
Assembly Process Status
AP selected
Id of Assembly process currently
selected
Batch size
Batch size (related to assembly
process)
Tight start Result received
Batch count
Batch count (related to assembly
process)
Tight start Result received
Batch remaining
Batch remaining (related to assembly
process)
Tight start Result received
