Desoutter CVI3 Vision User Manual

Appendix - Fieldbus_01/2016- 72 -
Name Description ASCII values
Numerical
values or
binary format
Reset
condition
Set condition
Pset Status
Pset selected If of Pset currently selected
Tightening result Tightening result
"“A” = accepted
“R” = rejected"
"0 = no result
1 = accepted
2 = rejected"
Tight start Result received
Final torque
Final torque in N.m. (last step); if used
with additional transducer this value
concerns the value of the transducer
in charge of control.
Tight start Result received
Torque trend
Torque trend (last step); if used with
additional transducer this value
concerns the value of the transducer
in charge of control.
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Min. torque
Min torque (last step); if used with
additional transducer this value
concerns the value of the transducer
in charge of control.
Tight start Result received
Target torque
Target torque (last step); if used
with additional transducer this value
concerns the value of the transducer
in charge of control.
Tight start Result received
Max torque
Max torque (last step); if used with
additional transducer this value
concerns the value of the transducer
in charge of control.
Tight start Result received
Final angle
Final angle in degrees (last step);
if used with additional transducer
this value concerns the value of the
transducer in charge of control.
Tight start Result received
Angle trend
Angle trend (last step); if used with
additional transducer this value
concerns the value of the transducer
in charge of control.
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Min. angle
Min angle in degrees (last step);
if used with additional transducer
this value concerns the value of the
transducer in charge of control.
Tight start Result received
Target angle
Target angle in degrees (last step);
if used with additional transducer
this value concerns the value of the
transducer in charge of control.
Tight start Result received
Max. angle
Max angle in degrees (last step);
if used with additional transducer
this value concerns the value of the
transducer in charge of control.
Tight start Result received
Final current Final current in Amps (last step) Tight start Result received
Current trend Current trend (last step)
""" ""
""<""
"">""
""="""
"0 = no result
1 = min
2 = max
3 = accepted"
Tight start Result received
Min current Min current in Amps (last step) Tight start Result received
Max. current Max current in Amps (last step) Tight start Result received
Final current % Current in % Tight start Result received
Min. current % Current in % Tight start Result received
Max. current % Current in % Tight start Result received
Rundown speed Rundown speed in rpm Tight start Result received
Downshift speed Downshift speed in rpm Tight start Result received
Downshift torque Downshift torque threshold Tight start Result received
Angle threshold
Threshold (in TU units) used to start
angle measure.
Tight start Result received
Torque offset Torque offset applied Tight start Result received
Final torque without
offset
Real torque applied to the joint without
considering torque offset
Tight start Result received
