FrameMaker Ver.5.5E(PC) DIS/REASSEMBLY, ADJUSTMENT FOR Di152/Di183
01.09.03
D-14
6. Remove four screws and the Power Supply Left
Cover.
7. Unplug one connector and remove the harness
from one edge cover.
8. Unplug one connector and remove the harness
from one wiring saddle.
9. Unplug one connector and remove the harness
from one wiring saddle.
10. Unplug three connectors and remove the har-
ness from two wiring saddles.
To Next Page
