15-3. Paper Empty Detection Mechanism
• The Paper Empty Sensor detects a sheet of paper on the Multiple Bypass.
15-4. Paper Take Up Control
Elevtrical Component Control Signal
Forward
Rotation
OFF Wiring Diagram
M1
PWB-A PJ7A-5 L H
17-G
PWB-A PJ7A-7 H H
Elevtrical Component Control Signal ON OFF Wiring Diagram
SL21 PWB-A PJ4A-2 L H 17-F
Elevtrical Component Control Signal Activated Deactivated Wiring Diagram
PC21 PWB-A PJ4A-5 L H 17-F
4021M034AA
<When Paper is not Present><When Paper is Present>
4021M035AA
Multiple Bypass Paper Empty Sensor PC21
Paper
H
L
Paper Set Start Key ON
ON
OFF
ON
OFF
Multiple Bypass Paper
Empty Sensor PC21
Multiple Bypass Solenoid
SL21
Main Motor M1
4021M512CA
