19-1. Fusing Unit Drive Mechanism
• The Fusing Unit is driven by a motor.
19-2. Fusing Rollers Pressure Mechanism
• To ensure that there is a certain width of area of contact between the Right and Left Fus-
ing Rollers, a pressure spring is used to press the Lower Fusing Roller up against the
Upper Fusing Roller.
4021M042AA
Main Motor M1
Right Fusing Roller
Left Fusing Roller
4021M043AA
Right Fusing Roller
Left Fusing Roller
Pressure Spring
