7. IMAGING UNIT (I/U)
• The IU integrates the PC Drum, Developing Unit, PC Drum Charge Corona, and the PC
Drum Cleaning Mechanism, all in one body.
4021M006AB
4021M007AB
PC Drum
Developing Unit
PC Drum Cleaning Mechanism
PC Drum Charge Corona
