(8) Void areas
Section Step Check Result Action
Output
system
1 Foreign matter is present along the
paper path.
YES • Remove foreign matter.
2 Paper dust plugs up the Paper Dust
Remover.
YES • Clean or change.
3 PC Drum Charge Corona, grid mesh,
and Comb Electrode are loose.
YES • Reinstall.
4 PC Drum Charge Corona contact is
dirty, scratchy, deformed, worn, or dam-
aged.
YES • Clean, correct, or
change.
5 Developing Roller is dirty, scratchy,
deformed, worn, or damaged.
YES • Clean or change.
6 Toner is even on Sleeve/Magnet Roller. NO • Adjust DB.
For details, see DIS/
REASSEMBLY,
ADJUSTMENT.
7 Developer is not even in the Developer
Mixing Chamber of IU.
YES • Even out developer in
the Developer Mixing
Chamber.
8 DB of IU is plugged with foreign matter
(such as paper dust).
YES • Remove foreign matter.
9 Image Transfer Roller is dirty, scratchy,
deformed, worn, or damaged.
YES • Clean, correct, or
change.
10 Image Transfer Roller Assy is installed
correctly.
NO • Reinstall.
11 Charge Neutralizing Plate is dirty,
scratchy, folded, or bent.
YES • Clean, correct, or
change.
12 Left Fusing Roller is dirty, scratchy,
deformed, or worn.
YES • Clean or change.
NO • Change IU.
