3. TECH.REP.MODE
• This mode allows the Tech. Rep. to set adjust, and/program various service functions.
3-1. Tech.Rep.Mode Menu Function Tree
---: Tech.Rep.Mode
---0: Control Panel LED Check
---1: Function “F- ”
F-1 : Paper Passage Test
F-2 : HV Output
F-8 : ATDC Sensor Automatic Adjustment
F12: Test Pattern Output
---2: Tech.Rep.Choice “c--”
c-1 : Maintenance Counter Count
c-2 : IU Life Stop
c-3 : ID Adjustment
c-4 : VG Adjustment
c-5 : Leading Edge Erase Adjustment
c-6 : Trailing Edge Erase Adjustment
c-7 : Top/Bottom Edge Erase Adjustment
c-8 : Loop Length Adjustment (1st Tray)
c-9 : Loop Length Adjustment (2nd Tray)
c10: Loop Length Adjustment (Bypass Tray)
c11: Priority FLS Setting
---3: Counter “cnt”
--1: PM Counter
--2: Maintenance Counter
--3: IU Life Counter
--4: Application Counter
--5: Jam Counter
--6: Trouble Counter
--7: Paper Size Counter
---4: ATDC Sensor Output
---5: Level History
---6: ROM Version Display
---7: Administrator No. Input
Vg (grid voltage)
Vb (developing bias voltage)
~
