6. IMAGE STABILIZATION SYSTEM
The following image stabilization controls are provided to ensure stabilized copy image.
Purpose Means Control
To stabilize image density. Vg/Vb control
The Vg/Vb control voltage is varied to bring
Vg/Vb to an appropriate level according to
the following settings.
• Tech. Rep. Choice: ID Adjustment
• Tech. Rep. Choice: VG Adjustment
• User's Choice: Print Density
• IU Life Counter
• Paper type
To stabilize image transfer.
Image transfer
output control
The image transfer output is varied to bring
the image transfer current to an appropriate
level according to the following conditions.
• Paper type
• Paper width
• B/W ratio of image
4021M066CA
