4. SEQUENTIAL EXPLANATION
Polygon Motor M2
Power Switch ON Start Key ON
Exposure Lamp LA2
Main Motor M1
Paper Take-Up Solenoid SL1
Synchronizing Roller Sensor PC1
Synchronizing Roller Clutch CL1
Developing Bias (VB) DC
Developing Bias (VB) AC
Image Transfer Bias (+)
Image Transfer Bias (–)
Exit Paper Sensor PC3
Power Supply Cooling
Fan Motor M4
Full speed
Speed reduction
Full speed
Speed reduction
Fusing Cooling Fan
Motor M3
150 ˚C Warm-up completed
Predrive
