12-1. Developing Unit Drive Mechanism
The rollers are driven through a gear train from the motor.
Elevtrical Component Control Signal
Forward
Rotation
OFF Wiring Diagram
M1
PWB-A PJ7A-5 L H
17-G
PWB-A PJ7A-7 H H
4021M008AB
Sleeve/Magnet Roller
3rd Toner Conveying Roller
1st Toner Conveying Roller
2nd Toner Conveying Roller
Main Motor M1
