FrameMaker Ver.5.5E(PC) DIS/REASSEMBLY, ADJUSTMENT FOR Di152/Di183
01.09.03
D-41
<Thermistor>
20. Snap off the retaining ring at the front of the Left
Fusing Roller and remove the washer and bush-
ing.
21. Snap off the retaining ring in the rear of the Left
Fusing Roller and remove the gear.
22. Remove the collar.
23. Remove the bushing.
24. Remove the Left Fusing Roller.
25. Remove one screw and the Thermistor.
