FrameMaker Ver.5.5E(PC) Di152/Di183 TROUBLESHOOTING
01.09.04
T-17
Step Check Result Action
4 Exit Paper Sensor (PC3) is opera-
tional.
<Check Procedure>
Check voltage across a Master Board
(copier: PWB-A) pin and GND when
the sensor is blocked.
• Voltage across PJ10A-3 and GND
When blocked: DC5 V
When unblocked: DC0 V
NO • Change Exit Paper Sensor (PC3).
YES • Change Master Board (copier:
PWB-A).
