FrameMaker Ver.5.5E(PC) Di152/Di183 TROUBLESHOOTING
01.09.04
T-48
Section Step Check Result Action
Input
system
1 Shading sheet reading portion (the por-
tion on the backside of the Original
Glass to which Original Width Scale is
affixed) is dirty.
YES • Clean.
2 CCD Board (copier: PWB-J) connector
is loose.
YES • Reconnect.
3 Control Board (copier: PWB-C) connec-
tor PJ1A is loose.
YES • Reconnect.
NO • Change Control Board
(copier: PWB-C).
• Change Master Board
(copier: PWB-A).
